Depth Capacity

HQ Rod size : 150 m

PQ Rod size : 50 m

Power Pack

Diesel Engine Kubota Type V1505-E2B-EU-X2 Max. Power 26.5 kW @3000 rpm

Hydraulic System

Max. Pressure (Factory Setting) 200 Bar

Rotary Drill Head

Top Drive Gearbox Single Line Rotation Motor 4000 Series

Type Disc Valve Eaton

Drill Mast and Feed System

Drilling Angle : 45-90 Degree

Pull Down Force : 2789 Kg @200 Bar

Pull Up Force : 4673 Kg @200 Bar

Feed Stroke : 1.8 m

Rod Pull : 3 m

Hydraulic Main Winch Assy

Rotation Motor 4000 Series (625 cc) Eaton Type Disc

Hydraulic Main Wireline Assy

Rotation Motor 2000 Series Eaton Type Disc Valve

Hydraulic Control Panel

P80-3 Monoblock Directional Control Valves

P80-4 Monoblock Directional Control Valves
